Properties of Liquid Silicone Foam Sponge
Liquid silicone foam sponge is a foamed material made from silicone rubber, possessing unique physical and chemical properties with wide-ranging applications. Below is a detailed analysis of its characteristics:
Basic Characteristics Overview
Liquid silicone foam sponge (LSR) is a liquid rubber material compared to solid high-temperature vulcanized silicone rubber, featuring the following fundamental traits:
- Excellent flowability: Its liquid state allows easier filling of complex-shaped molds during processing
- Fast vulcanization: Using platinum as a catalyst enables rapid double-liquid vulcanization
- Safe and eco-friendly: Fully meets food-grade requirements, being non-toxic and odorless
- Lightweight: Compared to solid foamed silicone sponge, it’s lighter in weight at the same volume with more uniform foaming
Physical Properties
Liquid silicone foam sponge exhibits outstanding physical performance:
| Property | Parameters/Performance | Description |
|---|---|---|
| Density | 0.16-0.20g/cm³ (after foaming) | Can be controlled at low levels through foaming treatment, with base density of 1.17g/cm³ |
| Elasticity | Shore A 10-50 | Soft touch with good compressibility and rebound elasticity |
| Temperature resistance | -50℃ to 200℃ (long-term) | Some products can withstand 400℃ short-term |
| Tear resistance | Excellent | Molecular structure contains over 5000 micron-level pores per square centimeter |
| Cushioning performance | 2-3 times better than ordinary TPU materials | Can instantly absorb 90% of impact energy |
Chemical Properties
Liquid silicone foam sponge demonstrates exceptional chemical stability:
- Chemical corrosion resistance: Essentially non-reactive except with strong alkalis and hydrofluoric acid
- Weather resistance: Resistant to water, ozone, and climate aging, difficult to be corroded by chemicals
- Flame retardancy: With additives can reach UL94-V0 grade, effectively reducing combustion risk
- Thermal stability: Maintains elasticity even in extreme temperature environments
Special Functional Properties
Liquid silicone foam sponge possesses multiple special functions making it indispensable in high-end manufacturing:
- Sealing performance
- Closed-cell structure creates effective barriers against moisture, liquids, and dust
- Recovers original shape after long-term compression, achieving watertight sealing
- Insulation performance
- High volume and surface resistivity provide excellent electrical insulation
- Prevents short circuits and leakage between electronic components
- Shock absorption
- High elasticity and energy dissipation effectively absorb and disperse mechanical vibrations and impact
- Improves drop impact resistance by 60% for sensitive components
- Thermal and acoustic insulation
- Porous structure effectively blocks sound wave conduction and heat flow transfer
- Maintains good thermal insulation performance even at 500℃
Typical Application Scenarios
Due to its exceptional properties, liquid silicone foam sponge is widely used in various fields:
| Application Field | Specific Uses | Advantageous Properties |
|---|---|---|
| New energy vehicles | Battery pack sealing, cell shock protection, thermal insulation filling | Flame retardant insulation, lightweight, high temperature resistance |
| Electronics | Phone case liners, circuit board heat dissipation, sensitive component protection | Shock absorption, thermal insulation, dust/waterproof |
| Medical devices | Breathing mask sealing layers, artificial organ materials | Biocompatibility, soft and comfortable |
| Construction | Curtain wall joint sealing, thermal bridge breaks | Weather resistance, thermal insulation |
| Household products | Baking molds, eco-friendly lunch box sealing rings | Food-grade safety, high temperature resistance |
Summary
As a high-performance material, liquid silicone foam sponge combines lightweight properties, extreme temperature resistance, excellent elasticity, superior sealing and insulation characteristics, making it an ideal choice for high-end fields including new energy, electronics, and medical applications. With advancements in material science, its performance continues to improve and applications expand.
